Power supply: switched-mode; modular; 750W; 36VDC; 237x100x41mm

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: UHP-750-36
    Manufacturer: MEAN WELL
    Manufacturer code: UHP-750-36
    • Output current
    • Supply voltage
    • Supply voltage
    • Operating temperature
    • Protection
    • Protection
    • Protection
    • Protection
    • Type of power supply
    • Series
    • Body dimensions
    • Output voltage
    • Additional functions
    • Efficiency
    • Number of outputs
    • Electrical connection
    • Kind of power supply
    • Kind of case

    218.09 € 218.09 € (wo VAT) 218.09 EUR

    218.09 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Power supply: switched-mode; modular; 750W; 36VDC; 237x100x41mm

    Output current 20.9A
    Supply voltage 90...264V AC, 127...370V DC
    Operating temperature -30...70°C
    Protection overheating, anti-overload, anti-overvoltage, short circuit protection
    Type of power supply switched-mode
    Series UHP-750
    Body dimensions 237x100x41mm
    Output voltage 36V DC
    Additional functions active PFC
    Efficiency 95%
    Number of outputs 1
    Electrical connection terminal block
    Kind of power supply modular
    Kind of case 270B
