Potentiometer: mounting; single turn,horizontal; 500Ω; 500mW

    Multiples: 1.0
    Minimum quantity: 2.0
    Product code: T73YE501KT20
    Manufacturer: VISHAY
    Manufacturer code: T73YE501KT20
    • Mounting
    • Power
    • Resistance
    • Operating temperature
    • IP rating
    • Tolerance
    • Terminal pitch
    • Max. operating voltage
    • Kind of potentiometer
    • Kind of potentiometer
    • Type of potentiometer
    • Track material
    • Characteristics
    • Mechanical rotation angle
    • Temperature coefficient
    • Potentiometer standard
    • Torque
    • Electrical rotation angle
    • Potentiometer features
    • Potentiometer series

    1.51 € 1.51 € (wo VAT) 1.51 EUR

    1.51 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Potentiometer: mounting; single turn,horizontal; 500Ω; 500mW

    Mounting THT
    Power 500mW
    Resistance 500Ω
    Operating temperature -55...125°C
    IP rating IP67
    Tolerance ±10%
    Terminal pitch 2.54x2.54mm
    Max. operating voltage 250V
    Kind of potentiometer horizontal, single turn
    Type of potentiometer mounting
    Track material cermet
    Characteristics linear
    Mechanical rotation angle 290 ±5°
    Temperature coefficient 100ppm/°C
    Potentiometer standard 1/4"
    Torque 2Ncm
    Electrical rotation angle 250 ±15°
    Potentiometer features clear scale reading
    Potentiometer series T73RYE
