Power supply: switched-mode; 1000W; 36VDC; 34A; OUT: 1; 2.08kg; 85%

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: SHP1000PS36
    Manufacturer: XP POWER
    Manufacturer code: SHP1000PS36
    • Output current
    • Supply voltage
    • Power
    • Operating temperature
    • Protection
    • Protection
    • Protection
    • Protection
    • Type of power supply
    • Application
    • Application
    • Output voltage
    • Additional functions
    • Additional functions
    • Insulation voltage
    • Efficiency
    • Number of outputs
    • Electrical connection

    589.07 € 589.07 € (wo VAT) 589.07 EUR

    589.07 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Power supply: switched-mode; 1000W; 36VDC; 34A; OUT: 1; 2.08kg; 85%

    Output current 34A
    Supply voltage 80...264V AC
    Power 1kW
    Operating temperature -40...70°C
    Protection anti-overload, anti-overvoltage, overheating, short circuit protection
    Type of power supply switched-mode
    Application IT, medical applications
    Output voltage 36V DC
    Additional functions auxiliary standby output 5V DC, remote ON/OFF control
    Insulation voltage 4kV
    Efficiency 85%
    Number of outputs 1
    Electrical connection screw terminals
