Module: GPS GLONASS; ±2.5m; GPS; -165dBm; 2.8÷4.3VDC; 9600bps; SMD

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: S2-105ZC
    Manufacturer: SIMCOM
    Manufacturer code: S2-105ZC
    • Mounting
    • Supply voltage
    • Operating temperature
    • Interface
    • Interface
    • Dimensions
    • Type of communications module
    • Position determination accuracy
    • Receiver sensitivity
    • Transmission
    • GPS features
    • GPS features
    • Transfer rate

    14.36 € 14.36 € (wo VAT) 14.36 EUR

    14.36 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Module: GPS GLONASS; ±2.5m; GPS; -165dBm; 2.8÷4.3VDC; 9600bps; SMD

    Mounting SMD
    Supply voltage 2.8...4.3V DC
    Operating temperature -40...85°C
    Interface PPS, UART
    Dimensions 10.1x9.7x2.5mm
    Type of communications module GPS
    Position determination accuracy ±2.5m
    Receiver sensitivity -165dBm
    Transmission GPS
    GPS features cold start <28s, Galileo
    Transfer rate 9.6kbps
