Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMT; LED; white

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: ML4L12WQR
    Manufacturer: DIPTRONICS
    Manufacturer code: ML4L12WQR
    • Mounting
    • Operating temperature
    • Type of switch
    • Number of positions
    • Leads
    • Max. contact resistance:
    • Terminal pitch
    • Mechanical durability
    • Backlight colour
    • Illumination
    • Contacts configuration
    • Switching method
    • Stable positions number
    • Operating Force
    • Button shape
    • Button height

    2.12 € 2.12 € (wo VAT) 2.12 EUR

    2.12 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMT; LED; white

    Mounting SMT
    Operating temperature -40...85°C
    Type of switch microswitch TACT
    Number of positions 2
    Leads straight
    Max. contact resistance: 100mΩ
    Terminal pitch 3.7mm
    Mechanical durability 1000000cycles
    Backlight colour white
    Illumination LED
    Contacts configuration SPST-NO
    Switching method OFF-(ON)
    Stable positions number 1
    Operating Force 1.56N
    Button shape square
    Button height 2mm
