Sensor: liquid level; -20÷130°C; lead 0,5m; Output conf: SPST-NO

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: LS03-1A85-PP-500W
    Manufacturer: MEDER
    Manufacturer code: LS03-1A85-PP-500W
    • Max. operating current
    • Operating temperature
    • Application
    • Application
    • Body material
    • Max. operating voltage
    • Max. operating voltage
    • Output configuration
    • Type of sensor
    • Switching capacity
    • Sensors features
    • Connection

    14.97 € 14.97 € (wo VAT) 14.97 EUR

    14.97 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Sensor: liquid level; -20÷130°C; lead 0,5m; Output conf: SPST-NO

    Max. operating current 1A
    Operating temperature -20...130°C
    Application dilute acids, water
    Body material polypropylene
    Max. operating voltage 1kV AC, 1kV DC
    Output configuration SPST-NO
    Type of sensor liquid level
    Switching capacity 100W
    Sensors features sensor for horizontal mounting
    Connection lead 0,5m
