Power supply: switched-mode; Mounting: for building in

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: HPU1K5PS24
    Manufacturer: XP POWER
    Manufacturer code: HPU1K5PS24
    • Output current
    • Supply voltage
    • Power
    • Operating temperature
    • Type of power supply
    • Output voltage
    • Additional functions
    • Insulation voltage
    • Efficiency
    • Output current 2
    • Output voltage 2
    • Number of outputs
    • Switching frequency

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Power supply: switched-mode; Mounting: for building in

    Output current 63A
    Supply voltage 85...264V AC
    Power 1.5kW
    Operating temperature -20...70°C
    Type of power supply switched-mode
    Output voltage 24V DC
    Additional functions auxiliary standby output 5V DC
    Insulation voltage 4kV
    Efficiency 90%
    Output current 2 1A
    Output voltage 2 5V DC
    Number of outputs 2
    Switching frequency 65kHz
