Meter: safety tester; TFT 7"; Utest: 0.05÷5kV; 1kVA; True RMS AC

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: GPT-15001
    Manufacturer: GW INSTEK
    Manufacturer code: GPT-15001
    • Supply voltage
    • Interface
    • Interface
    • Interface
    • Interface
    • Conform to the norm
    • Short circuit current
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • True effective value measurement
    • Dimensions (W x H x D)
    • Power VA

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Meter: safety tester; TFT 7"; Utest: 0.05÷5kV; 1kVA; True RMS AC

    Supply voltage 100...240V AC
    Interface GPIB, LAN (option), RS232, USB
    Conform to the norm IEC 61010-2-034
    Short circuit current 200mA
    Measuring instrument features 100 sets memory, manual/ auto mode, safety interlock function, statistics function, sweep function for DUT characteristic analysis
    Standard equipment cable GHT-115, cable GHT-119, interlock key, mains cable, user's manual
    True effective value measurement True RMS AC
    Dimensions (W x H x D) 380x148x492mm
    Power VA 1kVA
