Power supply: switched-mode; 350W; 85÷264VAC; OUT: 1; 28VDC; 7.1A
Multiples:
1.0
Minimum quantity:
1.0
Product code:
GCS350PS28
Manufacturer: XP POWER
Manufacturer code: GCS350PS28
Product downloads
Specification for Power supply: switched-mode; 350W; 85÷264VAC; OUT: 1; 28VDC; 7.1A
| Output current | 7.1A |
| Mounting | mounting holes |
| Supply voltage | 85...264V AC |
| Power | 350W |
| Operating temperature | -40...70°C |
| Protection | anti-overload, anti-overvoltage, overheating, short circuit protection |
| Type of power supply | switched-mode |
| Application | IT, medical applications |
| Output voltage | 28V DC |
| Insulation voltage | 4kV |
| Efficiency | 93% |
| Number of outputs | 1 |
| Electrical connection | connector with snap lock |
| Kind of power supply | open |
| Switching frequency | 150kHz |
