Power supply: switched-mode; 60W; 80÷264VAC; OUT: 1; 12VDC; 5A; 90%

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: ECS60US12
    Manufacturer: XP POWER
    Manufacturer code: ECS60US12
    • Output current
    • Mounting
    • Supply voltage
    • Power
    • Operating temperature
    • Protection
    • Protection
    • Protection
    • Type of power supply
    • Application
    • Application
    • Output voltage
    • Insulation voltage
    • Efficiency
    • Number of outputs
    • Electrical connection
    • Kind of power supply
    • Switching frequency

    53.86 € 53.86 € (wo VAT) 53.86 EUR

    53.86 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Power supply: switched-mode; 60W; 80÷264VAC; OUT: 1; 12VDC; 5A; 90%

    Output current 5A
    Mounting mounting holes
    Supply voltage 80...264V AC
    Power 60W
    Operating temperature -20...70°C
    Protection anti-overvoltage, short circuit protection, anti-overload
    Type of power supply switched-mode
    Application medical applications, IT
    Output voltage 12V DC
    Insulation voltage 4kV
    Efficiency 90%
    Number of outputs 1
    Electrical connection connector with snap lock
    Kind of power supply open
    Switching frequency 65kHz
