Power supply: switched-mode; 20W; 48VDC; 420mA; OUT: 1; 60g; 86%

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: ECE20US48
    Manufacturer: XP POWER
    Manufacturer code: ECE20US48
    • Output current
    • Mounting
    • Supply voltage
    • Supply voltage
    • Power
    • Operating temperature
    • Protection
    • Protection
    • Protection
    • Output voltage
    • Insulation voltage
    • Efficiency
    • Number of outputs
    • Electrical connection
    • Power supply unit features
    • Switching frequency

    42.77 € 42.77 € (wo VAT) 42.77 EUR

    42.77 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Power supply: switched-mode; 20W; 48VDC; 420mA; OUT: 1; 60g; 86%

    Output current 420mA
    Mounting PCB
    Supply voltage 85...264V AC, 120...370V DC
    Power 20W
    Operating temperature -25...70°C
    Protection anti-overload, anti-overvoltage, short circuit protection
    Output voltage 48V DC
    Insulation voltage 3kV
    Efficiency 86%
    Number of outputs 1
    Electrical connection THT
    Power supply unit features cooling passive
    Switching frequency 100kHz
