Module: level monitoring relay; conductive fluid level; DIN

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: CPW-3M
    Manufacturer: MIKROBEST
    Manufacturer code: CPW-3M
    • Mounting
    • Supply voltage
    • Protection
    • Protection
    • Type of module
    • Additional functions
    • Additional functions
    • Additional functions
    • Additional functions
    • Controlled parameter
    • Kind of output 1
    • Input 1 properties

    55.09 € 55.09 € (wo VAT) 55.09 EUR

    55.09 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Module: level monitoring relay; conductive fluid level; DIN

    Mounting for DIN rail mounting
    Supply voltage 230V AC
    Protection TVS diodes, fuse
    Type of module level monitoring relay
    Additional functions adjustable sensitivity and time of delay, control filling and draining of reservoirs with conductive fluids, dry running protection, maximum and minimum level control
    Controlled parameter conductive fluid level
    Kind of output 1 relay
    Input 1 properties electrodes supplied with 12V DC and power value depends on the setting of potentiometer sensitivity in 10-500mA range
