Switch: rotary; Pos: 4; 0.15A/250VDC; Poles number: 3; 30°; -30÷85°C

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: CK1031
    Manufacturer: LORLIN
    Manufacturer code: CK1031
    • Operating temperature
    • Type of switch
    • Contact plating
    • Number of positions
    • Leads
    • Fastening thread
    • Contact material
    • Body material
    • Mechanical durability
    • Min. insulation resistance
    • Shaft length
    • Shaft diameter
    • Shaft surface
    • Poles number
    • DC contacts rating @R
    • Switching method
    • Stable positions number
    • Switching torque
    • Indexed positions

    4.37 € 4.37 € (wo VAT) 4.37 EUR

    4.37 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Switch: rotary; Pos: 4; 0.15A/250VDC; Poles number: 3; 30°; -30÷85°C

    Operating temperature -30...85°C
    Type of switch rotary
    Contact plating silver plated
    Number of positions 4
    Leads for soldering
    Fastening thread M10x0,75
    Contact material brass
    Body material polyamide
    Mechanical durability 10000cycles
    Min. insulation resistance 999MΩ
    Shaft length 46mm
    Shaft diameter 6mm
    Shaft surface smooth
    Poles number 3
    DC contacts rating @R 0.15A / 250V DC
    Switching method BBM (non-shorting)
    Stable positions number 4
    Switching torque 8.6Ncm
    Indexed positions 30°
