Power supply: switched-mode; 390/500W; 80÷264VDC; 80÷264VAC; 94%
Multiples:
1.0
Minimum quantity:
1.0
Product code:
CFM500M480C
Manufacturer: CINCON
Manufacturer code: CFM500M480C
Product downloads
Specification for Power supply: switched-mode; 390/500W; 80÷264VDC; 80÷264VAC; 94%
| Supply voltage | 80...264V AC |
| Case | 5"x3" |
| Operating temperature | -40...85°C |
| Protection | overheating, short circuit protection, voltage drop |
| Type of power supply | switched-mode |
| Application | medical applications |
| Output voltage | 48V DC |
| Additional functions | active PFC, auxiliary DC output 12V/500mA, PFC |
| Insulation voltage | 4kV |
| Efficiency | 94% |
| Electrical connection | connector with snap lock |
| Kind of power supply | open |
| Power supply unit features | cooling passive |
| Switching frequency | 65kHz |
