Plug; 4mm banana; 30A; 60VDC; white; 3mΩ; 2.5mm2; nickel plated

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: BUELA 30 K WH
    Manufacturer: HIRSCHMANN T&M
    Manufacturer code: BUELA 30 K WH
    • Mounting
    • Operating temperature
    • Connector
    • Colour
    • Contact plating
    • Type of connector
    • Contact material
    • Max. contact resistance:
    • Current rating
    • Rated voltage
    • Connector variant
    • Connector variant
    • Max cable section
    • Connection

    2.04 € 2.04 € (wo VAT) 2.04 EUR

    2.04 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Plug; 4mm banana; 30A; 60VDC; white; 3mΩ; 2.5mm2; nickel plated

    Mounting on cable
    Operating temperature -25...70°C
    Connector plug
    Colour white
    Contact plating nickel plated
    Type of connector 4mm banana
    Contact material brass
    Max. contact resistance: 3mΩ
    Current rating 30A
    Rated voltage 60V DC
    Connector variant non-insulated, with 4mm transversal socket
    Max cable section 2.5mm<sup>2</sup>
    Connection soldering
