Switch: emergency stop; Stabl.pos: 2; NC + NO; 5A/250VAC; 5A/24VDC

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 84-5130.0040
    Manufacturer: EAO
    Manufacturer code: 84-5130.0040
    • Operating temperature
    • IP rating
    • Type of switch
    • Switches features
    • Number of positions
    • Leads
    • Mounting hole diameter
    • Cable length
    • Illumination
    • Face dimensions
    • Switch standard
    • Contacts configuration
    • DC contacts rating @R
    • AC contacts rating @R
    • Stable positions number
    • Actuator colour
    • Button shape
    • Button marking

    41.48 € 41.48 € (wo VAT) 41.480000000000004 EUR

    41.48 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Switch: emergency stop; Stabl.pos: 2; NC + NO; 5A/250VAC; 5A/24VDC

    Operating temperature -25...55°C
    IP rating IP65
    Type of switch emergency stop
    Switches features return by rotating
    Number of positions 2
    Leads cables
    Mounting hole diameter Ø22.5mm
    Cable length 300mm
    Illumination none
    Face dimensions Ø32mm
    Switch standard 22mm
    Contacts configuration NC + NO
    DC contacts rating @R 5A / 24V DC
    AC contacts rating @R 5A / 250V AC
    Stable positions number 2
    Actuator colour red
    Button shape mushroom
    Button marking arrows
