External amplifier; 12VDC; 1.1Ω; 46mA; 700mV; 3.2W; In.imp: 10kΩ

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 7102
    Manufacturer: VISATON
    Manufacturer code: 7102
    • Supply voltage
    • Operating temperature
    • Input voltage
    • Input impedance
    • Kind of input connector
    • Kind of input connector
    • Kind of output connector
    • Caution!
    • Quiescent current
    • Output impedance
    • Type of sound transducer
    • Channel output power

    42.46 € 42.46 € (wo VAT) 42.46 EUR

    42.46 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for External amplifier; 12VDC; 1.1Ω; 46mA; 700mV; 3.2W; In.imp: 10kΩ

    Supply voltage 12V DC
    Operating temperature -10...50°C
    Input voltage 700mV
    Input impedance 10kΩ
    Kind of input connector Jack 3.5 mm stereo, terminal DC: outer diam. 5,4 mm (-), inner diam. 2,1 mm (+)
    Kind of output connector Jack 3.5mm stereo
    Caution! Amplifier recommended for non-portable applications which have got high output power
    Quiescent current 46mA
    Output impedance 1.1Ω
    Type of sound transducer external amplifier
    Channel output power 3.2W
