Relay: electromagnetic; DPDT; Ucoil: 24VAC; 8A/250VAC; 8A/30VDC

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 46.52.8.024.0040
    Manufacturer: FINDER
    Manufacturer code: 46.52.8.024.0040
    • Mounting
    • Mounting
    • Operating temperature
    • Contact material
    • Terminal pitch
    • Body dimensions
    • Mechanical durability
    • Switched voltage
    • Switched voltage
    • Coil resistance
    • Contacts configuration
    • DC contacts rating @R
    • AC contacts rating @R
    • Contact current max.
    • Relay variant
    • Relay variant
    • Type of relay
    • Coil power consumption
    • Relay series

    12.38 € 12.38 € (wo VAT) 12.38 EUR

    12.38 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Relay: electromagnetic; DPDT; Ucoil: 24VAC; 8A/250VAC; 8A/30VDC

    Mounting PCB, socket
    Operating temperature -40...70°C
    Contact material AgNi
    Terminal pitch 5mm
    Body dimensions 29x12.4x32.8mm
    Mechanical durability 1000000cycles
    Switched voltage max. 220V DC, max. 440V AC
    Coil resistance 320Ω
    Contacts configuration DPDT
    DC contacts rating @R 8A / 30V DC
    AC contacts rating @R 8A / 250V AC
    Contact current max. 15A
    Relay variant industrial, miniature
    Type of relay electromagnetic
    Coil power consumption 1.2VA
    Relay series 46.52
