Motor: DC; with gearbox; LP; 12VDC; 1.1A; Shaft: D spring; 150rpm

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 34:1 25DX52L MM LP 12V
    Manufacturer: POLOLU
    Manufacturer code: 34:1 25DX52L MM LP 12V
    • Supply voltage
    • Max. operating current
    • Series
    • Operating current
    • Information
    • Shaft diameter
    • Shaft surface
    • Torque
    • Kind of motor
    • Type of motor
    • Nominal rot. speed measured after gear
    • Double sided shaft

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Specification for Motor: DC; with gearbox; LP; 12VDC; 1.1A; Shaft: D spring; 150rpm

    Supply voltage 12V DC
    Max. operating current 1.1A
    Series Low Power
    Operating current 100mA
    Information Product is not a working device, but only component
    Shaft diameter 4mm
    Shaft surface D spring
    Torque max. 303.6mNm
    Kind of motor with gearbox
    Type of motor DC
    Nominal rot. speed measured after gear 150rpm
    Double sided shaft no
