Wire; UL AWM 2095; 3x22AWG; braid made of copper wires; PVC; 300V

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 1737C SL005
    Manufacturer: ALPHA WIRE
    Manufacturer code: 1737C SL005
    • Operating temperature
    • Core structure
    • Kind of core
    • Kind of core
    • Number of cores
    • Wire insulation material
    • Kind of wire
    • Rated voltage
    • Cable external diameter
    • Insulation colour
    • Type of wire
    • Shield structure
    • Core marking
    • Earth core
    • CPR standard

    131.63 € 131.63 € (wo VAT) 131.63 EUR

    131.63 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Wire; UL AWM 2095; 3x22AWG; braid made of copper wires; PVC; 300V

    Operating temperature -20...60°C
    Core structure stranded
    Kind of core Cu, tinned
    Number of cores 3
    Wire insulation material PVC
    Kind of wire Alpha Essential C&C
    Rated voltage 300V
    Cable external diameter 5.05mm
    Insulation colour dark grey
    Type of wire control cable
    Shield structure braid made of copper wires
    Core marking colours without colour repetition
    Earth core without earth core
    CPR standard no classification
