Limit switch; metal roller Ø11,6mm; NO + NC; 10A; max.250VAC

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: XCKD2102M12
    Tootja: SCHNEIDER ELECTRIC
    Tootja tootekood: XCKD2102M12
    • Operating temperature
    • IP rating
    • Switches features
    • Number of pins
    • Body material
    • Body dimensions
    • Switched voltage
    • Switched voltage
    • Output configuration
    • Type of sensor
    • Number of mounting holes
    • DC contacts rating @R
    • AC contacts rating @R
    • Connection
    • Contact current max.
    • Kind of actuator

    56,01 € 56,01 € (KM-TA) 56.01 EUR

    56,01 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Limit switch; metal roller Ø11,6mm; NO + NC; 10A; max.250VAC

    Operating temperature -25...70°C
    IP rating IP67
    Switches features snap action contacts
    Number of pins 4
    Body material metal
    Body dimensions 31x65x30mm
    Switched voltage ≤ 250V AC, ≤ 250V DC
    Output configuration NO + NC
    Type of sensor limit switch
    Number of mounting holes 2
    DC contacts rating @R 270mA / 250V DC
    AC contacts rating @R 3A / 240V AC
    Connection connector M12
    Contact current max. 10A
    Kind of actuator metal roller Ø11,6mm
