Relay: reed; SPST-NO; Ucoil: 3VDC; 1A; max.200VDC; max.200VAC; 10W

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: S2-03P
    Tootja: SENSATA/CYNERGY3
    Tootja tootekood: S2-03P
    • Mounting
    • Operating temperature
    • Switched voltage
    • Switched voltage
    • Min. insulation resistance
    • Switching capacity
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • Contact current max.
    • Type of relay
    • Operate time

    0,00 € 0,00 € (KM-TA) 0.0 EUR

    0,00 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: reed; SPST-NO; Ucoil: 3VDC; 1A; max.200VDC; max.200VAC; 10W

    Mounting PCB
    Operating temperature -40...85°C
    Switched voltage ≤ 200V DC, ≤ 200V AC
    Min. insulation resistance 10TΩ
    Switching capacity 10W
    Coil resistance 250Ω
    Rated coil voltage 3V DC
    Contacts configuration SPST-NO
    Contact current max. 1A
    Type of relay reed
    Operate time 100µs
