Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 60A; automotive
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
HFKP/024-1H4T
Tootja: HONGFA RELAY
Tootja tootekood: HFKP/024-1H4T
Product downloads
Spetsifikatsioon tootele Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 60A; automotive
Mounting | PCB |
Operating temperature | -40...125°C |
Contact material | AgSnO<sub>2</sub> |
Body dimensions | 22x26.5x22.3mm |
Switched voltage | ≤ 75V DC |
Coil resistance | 362Ω |
Rated coil voltage | 24V DC |
Contacts configuration | SPST-NO |
DC contacts rating @R | 45A / 12V DC |
Contact current max. | 60A |
Relay variant | automotive |
Coil voltage max. | 28.6V DC |
Type of relay | electromagnetic |
Coil voltage min. | 13.9V DC |
Coil power consumption | 1.6W |
