DC-motor driver; on panel; Electr.connect: screw terminals; 80W

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: EM-185
    Tootja:
    Tootja tootekood:
    • Mounting
    • Supply voltage
    • Operating temperature
    • Protection
    • Protection
    • Type of module
    • Output frequency
    • Additional functions
    • Additional functions
    • Additional functions
    • Additional functions
    • Electrical connection
    • Max motor power
    • Rated continuous current

    130,79 € 130,79 € (KM-TA) 130.79 EUR

    130,79 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Spetsifikatsioon tootele DC-motor driver; on panel; Electr.connect: screw terminals; 80W

    Mounting on panel
    Supply voltage 12...32V DC
    Operating temperature 0...60°C
    Protection anti-overload, short circuit protection
    Type of module DC-motor driver
    Output frequency 25kHz
    Additional functions max momentary current-6A (10s), PWM, regulation knob, starting current limiter
    Electrical connection screw terminals
    Max motor power 80W
    Rated continuous current 3A
