Microswitch SNAP ACTION; without lever; SPST-NO; 0.1A/6VDC; IP40

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: D2FS-F-N-A
    Tootja: OMRON OCB
    Tootja tootekood: D2FS-F-N-A
    • Operating temperature
    • IP rating
    • Type of switch
    • Switches features
    • Number of positions
    • Leads
    • Leads
    • Leads
    • Contact material
    • Max. contact resistance
    • Terminal pitch
    • Body material
    • Body dimensions
    • Mechanical durability
    • Electrical life
    • Key stroke
    • Contacts configuration
    • DC contacts rating @R
    • Switching method
    • Stable positions number
    • Operating Force

    1,90 € 1,90 € (KM-TA) 1.9000000000000001 EUR

    1,90 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Microswitch SNAP ACTION; without lever; SPST-NO; 0.1A/6VDC; IP40

    Operating temperature -20...70°C
    IP rating IP40
    Type of switch microswitch SNAP ACTION
    Switches features without lever
    Number of positions 2
    Leads angled, for PCB, right
    Contact material silver
    Max. contact resistance 100mΩ
    Terminal pitch 5.08mm
    Body material plastic
    Body dimensions 12.8x6.5x5.8mm
    Mechanical durability 100000cycles
    Electrical life 10000cycles
    Key stroke 0.5mm
    Contacts configuration SPST-NO
    DC contacts rating @R 100mA / 6V DC
    Switching method OFF-(ON)
    Stable positions number 1
    Operating Force 850mN
