Relay: electromagnetic power; SPST-NO + SPST-NC; Ucoil: 12VDC

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: AZEV132-1AE1BG-12D
    Tootja: ZETTLER
    Tootja tootekood: AZEV132-1AE1BG-12D
    • Mounting
    • Operating temperature
    • Contact material
    • Switched voltage
    • Rated coil voltage
    • Contacts configuration
    • Contact resistance
    • AC contacts rating @R
    • Contact current max.

    8,73 € 8,73 € (KM-TA) 8.73 EUR

    8,73 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: electromagnetic power; SPST-NO + SPST-NC; Ucoil: 12VDC

    Mounting PCB
    Operating temperature -40...85°C
    Contact material AgSnO<sub>2</sub>
    Switched voltage ≤ 400V AC
    Rated coil voltage 12V DC
    Contacts configuration SPST-NO + SPST-NC
    Contact resistance 3mΩ
    AC contacts rating @R 40A / 277V AC
    Contact current max. 40A
