Scopemeter; Band: ≤100MHz; Channels: 4; 100kpts/ch; IP54; -20÷70°C

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: OX9104
    Manufacturer: METRIX
    Manufacturer code: OX9104
    • IP rating
    • Number of channels
    • Interface
    • Interface
    • Interface
    • Interface
    • Dimensions
    • Kind of display used
    • Display resolution
    • Max. input voltage
    • Trigger
    • Trigger
    • Trigger
    • Trigger
    • Trigger
    • Conform to the norm
    • Conform to the norm
    • Optional equipment
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Standard equipment
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Measurement
    • Sampling
    • Sampling
    • Type of oscilloscope
    • Trigger modes
    • Trigger modes
    • Trigger modes
    • Trigger modes
    • Vertical resolution
    • Input coupling
    • Trigger source
    • Trigger source
    • Trigger source
    • Trigger source
    • Trigger coupling
    • Trigger coupling
    • Trigger coupling
    • Trigger coupling
    • Trigger coupling
    • Trigger coupling

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Scopemeter; Band: ≤100MHz; Channels: 4; 100kpts/ch; IP54; -20÷70°C

    IP rating IP54
    Number of channels 4
    Interface Ethernet, microSD, USB, WiFi
    Dimensions 292.5x210.6x66.2mm
    Kind of display used color
    Display resolution 800x480
    Max. input voltage 0.6/1kV
    Trigger counting, falling-edge, impulse width, rising-edge, with delay
    Conform to the norm CAT III 600V, EN 61010
    Optional equipment ProbiX accessories
    Measuring instrument features automatic accessories recognition, EF function - electrical field detecion, harmonic analyser mode, insulated inputs, logger mode, mathematical functions: addition, subtraction, division, multiplication and FFT, measurements by means of cursors, multilanguage menu, zoom function accessible with one button
    Standard equipment adaptor USB/microSD, battery charger/power supply, carrying case, Ethernet cable, high voltage probe (1 per channel), mains cable, manual (CD), microSD 8GB memory card, ProbiX banana, ProbiX BNC, stylus, test leads, test probes, USB cable, wristbands
    Measurement AC voltage, active power, apparent power, capacitance, DC voltage, frequency, harmonic content factor, harmonics, power factor, reactive power, resistance, temperature (option)
    Sampling 100Gsps (in equivalent time), 2,5Gsps
    Type of oscilloscope hand oscilloscope
    Trigger modes auto level 50%, automatic, single-shot, triggered
    Vertical resolution 12bit
    Input coupling AC, DC, GND
    Trigger source CH1, CH2, CH3, CH4
    Trigger coupling AC, DC, highpass, Hold-Off adjustable: 64ns - 15s, lowpass, noise - level
