Current loop clamp meter; LCD 3,5 digit; IP42; 4.5mm
Multiples:
1.0
Minimum quantity:
1.0
Product code:
FLK-A3004FC
Manufacturer: FLUKE
Manufacturer code: FLK-A3004FC
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABC2AD97901E80D6&compId=MEASURING.txt?ci_sign=d0ccb06ee923cc677e69012bfb5fb7bd92f37df8
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB6D412F7421DC&compId=INB-MIER-EN.pdf?ci_sign=9f97fafdfd0fa92910eac1938c04e02cb683e79f
- pVersion=0046&contRep=ZT&docId=005056AB752F1EE59CCF4429D084611C&compId=6001874B-EN-FC-Reasons-Why-Flyer-w.pdf?ci_sign=da606f061daab71629ac91be27a63bb69521bd00
- pVersion=0046&contRep=ZT&docId=005056AB90B41ED9B7BC849B574700C4&compId=FLK-374FC.txt?ci_sign=4bc20bfeaa3e8d2cbf19d4abf981f7203e1f301b
Specification for Current loop clamp meter; LCD 3,5 digit; IP42; 4.5mm
| Operating temperature | -10...50°C |
| IP rating | IP42 |
| Dimensions | 165x635x356mm |
| Kind of display used | LCD |
| Measuring instrument features | datalogging, transfer measurement data wireless |
| Max jaw capacity | 4.5mm |
| Type of meter | current loop clamp meter |
| Measurement | 4-20mA current loop |
| Signal measurements | 0-20.99mA (0,01mA resolution, accuracy: 0,2% + 5 digits), 21-99,9mA (0,1mA resolution, accuracy: 1% + 5 digits) |
