Meter; on panel; analogue; 0÷6kV; True RMS; Class: 1,5; 40÷72Hz

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: EA12N C70200000000
    Manufacturer: LUMEL
    Manufacturer code: EA12N C70200000000
    • Mounting
    • IP rating
    • Series
    • Frequency
    • Max. voltage
    • Measuring instrument features
    • Measuring instrument features
    • Standard equipment
    • Scale length
    • Type of meter
    • Measurement
    • True effective value measurement
    • Kind of meter
    • Kind of meter
    • Dimensions (W x H x D)

    60.61 € 60.61 € (wo VAT) 60.61 EUR

    60.61 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Meter; on panel; analogue; 0÷6kV; True RMS; Class: 1,5; 40÷72Hz

    Mounting on panel
    IP rating IP52
    Series EA12
    Frequency 40...72Hz
    Max. voltage 600V
    Measuring instrument features for use with voltage transformers 100V, with overload to 10kV
    Standard equipment mounting holder x4
    Scale length 146mm
    Type of meter voltmeter
    Measurement AC voltage
    True effective value measurement True RMS
    Kind of meter mounting, analogue
    Dimensions (W x H x D) 144x144mm
