Meter; on panel; analogue; 0÷80A; IP40; 96x96mm; 300V; 300g

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: BE391NF4152000
    Manufacturer: LUMEL
    Manufacturer code: BE391NF4152000
    • Mounting
    • Mounting
    • IP rating
    • Series
    • Max. voltage
    • Accuracy class
    • Accuracy class
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Measuring instrument features
    • Standard equipment
    • Type of meter
    • Measurement
    • Kind of meter
    • Kind of meter
    • Dimensions (W x H x D)

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Meter; on panel; analogue; 0÷80A; IP40; 96x96mm; 300V; 300g

    Mounting on panel, for DIN rail mounting (optional)
    IP rating IP40
    Series BE39
    Max. voltage 300V
    Accuracy class 1,5 moving-iron movement, 3 bimetallic movement
    Measuring instrument features measurement of instantaneous current, shows the highest value reached current, indicates mean RMS current over 8 minutes, with overload to 96A
    Standard equipment mounting holder x2
    Type of meter amperometer
    Measurement AC current
    Kind of meter mounting, analogue
    Dimensions (W x H x D) 96x96x64mm
