Relay: reed; SPST-NO; Ucoil: 5VDC; 1A; max.100VDC; 10W; Rcoil: 500Ω

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: D71A2100
    Tootja: CELDUC
    Tootja tootekood: D71A2100
    • Mounting
    • Case
    • Operating temperature
    • Terminal pitch
    • Body dimensions
    • Switched voltage
    • Switching capacity
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • Contact resistance
    • Contact current max.
    • Coil voltage max.
    • Type of relay
    • Coil voltage min.
    • Relay series

    7,29 € 7,29 € (KM-TA) 7.29 EUR

    7,29 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: reed; SPST-NO; Ucoil: 5VDC; 1A; max.100VDC; 10W; Rcoil: 500Ω

    Mounting PCB
    Case DIP14
    Operating temperature -40...85°C
    Terminal pitch 2.54mm
    Body dimensions 19.9x7.62x5.5mm
    Switched voltage ≤ 100V DC
    Switching capacity 10W
    Coil resistance 500Ω
    Rated coil voltage 5V DC
    Contacts configuration SPST-NO
    Contact resistance 150mΩ
    Contact current max. 1A
    Coil voltage max. 16V DC
    Type of relay reed
    Coil voltage min. 3.75V DC
    Relay series D71A.1.0
