Switch: vandal resistant; Pos: 2; SPDT; 0.5A/220VAC; 1A/24VDC; IP67

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: LAS1-AGQPF-11Z/S
    Manufacturer: ONPOW
    Manufacturer code: LAS1-AGQPF-11Z/S
    • Operating temperature
    • IP rating
    • Type of switch
    • Number of positions
    • Leads
    • Contact material
    • Max. contact resistance:
    • Body material
    • Mounting hole diameter
    • Body colour
    • Mechanical durability
    • Electrical life
    • Test voltage
    • Contacts configuration
    • DC contacts rating @R
    • AC contacts rating @R
    • Switching method
    • Stable positions number
    • Operating Force
    • Button shape
    • Ring shape

    12.11 € 12.11 € (wo VAT) 12.11 EUR

    12.11 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Switch: vandal resistant; Pos: 2; SPDT; 0.5A/220VAC; 1A/24VDC; IP67

    Operating temperature -20...55°C
    IP rating IP67
    Type of switch vandal resistant
    Number of positions 2
    Leads for soldering
    Contact material silver alloy
    Max. contact resistance: 50mΩ
    Body material stainless steel
    Mounting hole diameter Ø19mm
    Body colour silver
    Mechanical durability 1000000cycles
    Electrical life 50000cycles
    Test voltage 1.5kV
    Contacts configuration SPDT
    DC contacts rating @R 1A / 24V DC
    AC contacts rating @R 0.5A / 220V AC
    Switching method ON-ON
    Stable positions number 2
    Operating Force 4N
    Button shape flat
    Ring shape flat
